THERM 4300 butane gas fireplace for mobile homes.

THERM 4300 butane gas fireplace for mobile homes.

Technical specifications:

Rated power Pn kW 11,8

Minimum power Pmin kW 7,8

Minimum power (50 mbar) Pmin kW 8,6

Setting range kW 7.8 - 11.8

Control range (50 mbar) kW 8,6 - 11,8

Heat load Qn kW 13,5

Minimum heat load Qmin kW 8,9

Minimum heat load (50 mbar) Qmin kW 9,8

100% efficiency% of the nominal load % 88

Yield at 30% of the nominal load % 88

Pressure of the gas supply:

Butane G30 mbar 28-30

Propane G31 mbar 37

Butane/Propane (NL) G30/G31 mbar 30

Butane/Propane (DE) G30/G31 mbar 50

Gas consumption Butane G30 kg/h 1,1 Propane G31 kg/h 1,1

Max. permissible operating pressure pw bar 12

Minimum working pressure pwmin bar 0,55

Minimum operating pressure at maximum volume flow bar 1

Maximum cold water inlet temperature °C 23

Starting flow rate l/min 2,6

Maximum volume flow, corresponding to a temperature increase of 25 °C l/min 6.7

Flow rate of combustion products g/s 15.3

Flue gas temperature at measuring points °C 190

Permissible ambient temperature °C 5-45

Height mm 580 Width mm 310 Depth mm 225.

Ref: 7736504932
