IRO light panel 595x595 mm 4000k with driver

IRO light panel 595x595 mm 4000k with RESISTEX driver part no. 621442

Commercial recessed luminaire with SMD LED circuit board.

Luminous efficiency of complete system 145lm/W.

L90F10 flux maintained for over 72,000 hours (Ta25°C).

Prismatic diffuserdesigned for low UGR

Semi-flush mounting with accessory 621435.

Ceiling mounting with accessory 621433 / Suspension mounting with accessory 899404.

Remote constant-current "Flicker-Free" driver with quick connector.

Direct-insertion push-button terminal block with double jumper line (1.5/2.5mm² cross-section).

Mechanical characteristics :

Color: white.

Body: aluminum.

Diffuser: polycarbonate.

Installation: recessed ceiling.

Immersion: no.

IP Recessed: 40.

Adjustability: fixed.

Luminaire weight: 2.26 kg.

Fixture length: 595 mm.

Fixture width: 595mm.

Fixture height: 35 mm.

Cut-out length: 600 mm.

Cutting width: 600 mm.

Driver weight: 0.182 kg.

Recoatable: no.

Glow wire temperature: 650°C.

IK : 04.

Electrical characteristics :

Voltage range: 220-240 V/50-60 Hz.

Luminaire wattage: 29.9 W.

Source power: 26.1 W.

Driver yield: 91 %.

Number of sources: 1.

Ta min/max: -25°C/40°C.

Tc: 90°C.

Power source: constant current driver.

Input signals: AC.

Driver output voltage: 39 V.

Driver output amperage: 750 mA.

Power/cos factor: 0.98.

Carbon footprint: 2.69 gCO2/h.

Short-circuit protection: yes.

Overheating protection: yes.

Overload protection: yes.

Leakage current:

Harmonic distortion rate :

Photometric characteristics :

Color temperature: 4000K.

Source type: LED module.

Luminous efficiency without power supply: 166lm/W.

Output at Ta 25°C: 4342lm.

Complete product luminous efficacy: 145lm/W.

Luminous efficiency (LOR): 100%.

Light emission: direct/symmetrical.

Beam angle: 92°.

Diffuser: opalescent.

CRI: 80.

Photobiological risk: risk group 0.

Number of MacAdam ellipses :

4000K coordinates: x: 0.3810; y: 0.3770.

UGR type :

LM80: L90F10 > 72000h (Ta25°C).

CIE n°3 flow code: 97%.

ULR : 0%.

Nominal characteristics :

Energy saving certificate: BAT-EQ-127.
